Carrier Heat Pumps
Carrier Heat Pumps in Frisco, TX
25HNB9 Infinity™ 19
The Carrier Infinity® 19 Series Two-Stage Heat Pump, with Puron® refrigerant, Model 25HNB9, is available in 3 to 5 ton nominal-sized units.
Energy Efficiency
- 14 – 19 SEER / 10.7 – 13.7 EER / 8.2 – 10.0 HSPF
- Microtube Technology™ refrigeration system
- Indoor air quality accessories available
Sound
- Sound level as low as 65 dBA
- Quiet mount split post compressor grommets
- Forward-swept condenser fan blade
- Compressor sound hood
- Laminated steel compressor mounting plate
- Electronic ECM ball bearing outdoor condenser fan motor
WeatherArmor Protection Package
- Solid, durable sheet metal construction
- Baked-on, complete outer coverage, powder paint
- Louver coil guard
Comfort
- System support Infinity Control or standard 2-stage thermostat controls
Reliability
- Crankcase Heater Standard
- Puron® refrigerant
- Front-seating service valves
- Filter Drier
- 2-stage scroll compressor
- High-Pressure Switch
- Internal thermal overload
- Loss of charge switch
- Internal pressure relief valve
- Balanced refrigeration system for maximum reliability
Controls and Diagnostics
- Infinity Control or Thermostat
- Utility Interface Connection
- Up to 83 point diagnostic capability with Infinity Control
Applications
- Long-line – up to 250 ft (76.2 m) total equivalent length, up to 200 ft (60.96 m) condenser above evaporator, or up to 80 ft (24.38 m) evaporator above condenser
25HCB6 Performance™ 16
Carrier Performance™ 16 2-Stage Heat Pump with Puron® Refrigerant, Model 25HCB6, is available in 2-5 ton nominal-sized units.
Energy Efficiency
- 15.5 – 16.5 SEER / 12.5 EER / 9.0 – 9.5 HSPF
(based on tested combinations)
Aesthetic Design
- WeatherArmor™ System
- Baked-on powder paint
- Steel-louver Coil Guard
Quiet Operation
- Sound as low as 70 dBA
Reliability, Quality and Durability
- Scroll Compressor
- Field-installed Filter Drier
- Front-seating Service Valves
- High-Pressure Switch
- Loss-of-Charge Switch
- Internal Pressure-Relief Valve
- Internal thermal overload
- Suction Line Accumulator
- Crankcase Heater Standard
25HBB3 Base 13
Carrier Base 13 SEER Heat Pump with Puron® Refrigerant, Model 25HBB3, is available in 1.5-5 ton nominal sized units.
Reliability, Quality and Durability
- Scroll Compressor
- Field installed Filter Drier
- High-Pressure/Loss-of-Charge Switches
- Front-seating Service Valves
- Internal Pressure-Relief Valve
- Internal thermal overload
- Baked-on powder paint
- Dense wire Coil Guard
- Suction-line Accumulator
Energy Efficiency
- 13 SEER / 10.1-10.8 EER /7.7-8.3 HSPF
Sound
- Sound as low as 70 dBA with accessory sound blanket
